RP-X924

Austin Hughes

Cyberview RP-X924 is a 9U 24" WUXGA (1920x1200) LED rackmount LCD monitor with VGA/DVI-D/HDMI inputs

The RP-X924 is a 9U 24" WUXGA (1920x1200) LED rackmount LCD monitor with features such as a built in On-Sreen-Display menu to provide effective assistance for an administrator to control multiple PCs. The RP series provides a cost effective rackmount monitor solution for your limited IT budget in a space saving, highly customizable package.



RP-X924 Benefits

  • 9U 24" LED LCD display panel
  • 1920 x 1200 WUXGA native resolution / 16.7M colors
  • HDMI 1.3 + DVI-D + VGA video input
  • PIP Sub-screen & PBP Dual-screen viewing efficiency
  • 2-year standard warranty ( upgradable up to 5 years )

Available Upgrades for RP-X924

  • Audio speakers + input & output
  • 3G / HD / SD-SDI Broadcast-grade input
  • MCS Multi display OSD controller
  • MIL-type or lockable connector
  • DC power : 12V / 24V / 48V / 110 ~ 125V
  • Touchscreen: Resistive 1-pt

RP-X924 Specifications

Mechanical
Product Dimensions (H x W x D) 15.2 x 21.8 x 2.8 in
( 385 x 553 x 70 mm )
Package Dimensions (H x W x D) 20.8 x 23 x 4.9 in
( 529 x 583 x 124 mm )
Net Weight 25.1 lb ( 11.4 kg )
Gross Weight 28 lb ( 12.7 kg )
Mounting
Rackmount 9U
VESA mount 100*100 mm
Console Ports
Video Input HDMI 1.3 + DVI-D single link + VGA
LCD Screen
LCD panel size ( diagonal ) 24.1"
Backlight type LED
Native resolution 1920 x 1200
Brightness (cd/m2) 300
Colors 16.7 M
Contrast Ratio (typ) 1000 : 1
Viewing angle ( L/R/U/D ) 89/89/89/89
Response time ( ms ) 14
Dot pitch ( mm ) 0.27
Display area ( mm ) 518.4H x 324V
Surface treatment Anti-glare, Hard-coating
Surface hardness 3H
MTBF (hrs) 30,000
Audio Option
Speaker 2x 2W (Dual Stereo)
Input Connector 3.5mm stereo jack
Input Impedance / Power level 30? / 750mV
Output Connector 3.5mm stereo jack
Output Impedance / Power level 30? / 2.8V
Power
Power Input Auto-sensing 100 to 240VAC, 50 / 60Hz
Power Consumption
Screen on Max. 40W
Power saving mode Max. 5W
Power button on Max. 1W
Environmental
Operating Temperature 0 to 55°C Degree
Storage Temperature -20 to 60°C Degree
Operating Humidity 20~90%, non-condensing
Relative Humidity 5~90%, non-condensing
Operating Altitude 16,000 ft
Non-operating Altitude 40,000 ft
Shock 10G acceleration (11ms duration)
Vibration 10~300Hz 0.5G RMS random vibration
Regulatory Compliance
EMC FCC & CE certified
Safety CE / LVD certified
Environment RoHS2 & REACH compliant
