OG-CM8148-AU

Opengear

Opengear CM8148 Console Server, 48 Serial Straight Pinout, 32GB Storage, 1GbE, AU power cord


Opengear CM8148 Console Server, 48 Serial Straight Pinout, 32GB Storage, 1GbE, AU power cord

The CM8100 is Opengear’s newest console manager for data centers and enterprise networks. Building on 18 years of Opengear product innovation and leadership, the CM8100 Console Manager provides up to 48 serial ports, enterprise-grade security using TPM 2.0 module, and independent monitoring using dual power supplies.

Connect 16, 32, or 48 serial console ports with simple straight-through cabling to Cisco®-style serial consoles reliably regardless of the state of your production network. Host containerized applications to run across any platform or NetOps tools providing more agility and efficiency. Maximize your connectivity and keep data free from slowdowns with Dual Ethernet ports. Manage at scale through Opengear’s Lighthouse Management Software. Designed and purpose-built energy efficient without compromising performance, the CM8100 requires less power and cooling for a lower total cost of ownership and high reliability.



  • 16, 32 or 48 port serial console server with Smart Out-of-Band™
  • Enables Data Center and Enterprise Network automation with Python and Docker support
  • Ideal replacement for legacy terminal servers
  • Embedded physical security using TPM 2.0 module
  • Dual power supplies with independent monitoring
  • Integrated environmental temperature monitoring

General Information
Category Multistation access units (MAUs)
Description Opengear CM8148 - Console server - 48 ports - GigE, RS-232 - 1U - rack-mountable
Manufacturer Opengear

UNSPSC 43222630
Main Specifications
Dimensions & Weight / Depth 23.5 cm
Dimensions & Weight / Height 4.4 cm
Dimensions & Weight / Weight 4.5 kg
Dimensions & Weight / Width 44 cm
Header / Brand Opengear
Header / Country Kits Australia
Miscellaneous / Product Color
  • Black
  • Red
Networking / Connectivity Technology Wired
Networking / Data Link Protocol
  • Ethernet
  • Fast Ethernet
  • Gigabit Ethernet
  • RS-232
Networking / Data Transfer Rate 230.4 Kbps
Networking / Form Factor Rack-mountable
Networking / Ports Qty 48
Networking / Type Console server
Packaged Quantity 1
Service & Support / Type 4-year warranty
Environmental Parameters
Humidity Range Operating 5 - 90% (non-condensing)
Max Operating Temperature 50 °C
Min Operating Temperature 5 °C
Expansion / Connectivity
Interfaces
  • 48 x RS-232 - RJ-45
  • 2 x 1000Base-T - RJ-45
  • 2 x USB 3.0 - Type A
  • 1 x console - RJ-45
General
Built-in Devices Temperature sensor
Depth 23.5 cm
Device Type Console server
Height 4.4 cm
Height (Rack Units) 1U
Localization Australia
Weight 4.5 kg
Width 44 cm
Manufacturer Warranty
Service & Support
  • Limited warranty - 4 years
  • Technical support - 4 years
Miscellaneous
Cables Included
  • 1 x patch cable - 1.83 m
  • 1 x DB-9 to RJ-45 adapter
Compliant Standards RoHS, FCC Part 15 B Class A, CNS13438:2006, EN 61000-4-2:2009, EN 61000-4-11:2004, IEC 61000-4-2:2008, IEC 61000-4-8:2009, IEC 61000-4-11:2004, EN 61000-3-3:2013, IEC 61000-3-3:2013, EN 61000-4-3:2006+A1:2008+A2:2010, IEC 61000-4-4:2012, IEC 61000-4-3:2006+A1:2007+A2:2010, AS/NZS CISPR 32:2015, IEC 62368, EN 55035:2017, CISPR 32:2016, VCCI 32, EN 61000-4-4:2012, EN 61000-3-2:2019, EN 55032:2017, ICES-003 issue 7, IEC 61000-3-2:2018
Included Accessories Rack mount kit, 4 x screws, 2 rack mounting ears, nuts
MTBF 150,000 hours
Networking
Authentication Method Secure Shell (SSH), RADIUS, TACACS+, LDAP, Active Directory
Connectivity Technology Wired
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet, RS-232
Data Transfer Rate 230.4 Kbps
Features Firewall protection, VPN support, temperature sensor, Management Information Base (MIB), Authentication, Authorization and Accounting (AAA), Trusted Platform Module 2.0 (TPM 2.0), ESD Protector, Smart Out-of-Band
Form Factor Rack-mountable
Network / Transport Protocol IPSec, IPv6
Ports Qty 48
Remote Management Protocol SNMP, HTTP, SSH, IPv6
Power
Installed Qty 2
Max Supported Qty 2
Power Consumption Operational 15 Watt
Power Device Internal power supply
Power Redundancy Yes
Voltage Required AC 100-240 V
Processor / Memory / Storage
Flash Memory 32 GB
Max Supported Qty 1
Processors Installed 1 x Marvell 88F6820 1.6 GHz
RAM 2 GB DDR4 SDRAM
